Product data

The IUY rod seal kit consists of two products:

1/IUW / IUW2 boot made of NBR85 (specification WYS A9516)

Ød=120 mm; ØD=140 mm; h=10 mm

2/ BRDW support ring made of Polyamide (Nylon) PA6 + MoS₂ + Impact Modifier Y7116

Ød=120 mm; ØD=140 mm; t=3 mm

The material PA6 + MoS₂ + Impact Modifier Y7116 is a high-tech, modified Polyamide 6 (Nylon), designed for components subjected to extreme mechanical loads. Thanks to the added molybdenum disulfide (MoS₂), the part has self-lubricating properties and an extremely low coefficient of friction. The built-in impact modifier Y7116 provides high toughness of the material, protecting it from cracking and breaking under heavy hydraulic peaks, vibrations and operation in conditions of low winter temperatures.

Overall product dimensions:

Ød=120 mm; ØD=140 mm; h+t=13 mm

Application range (the following limit values ​​must not be present at the same time):

Pressure: ≤ 300 bar
Speed: ≤ 0.03~1.0 m/s
Temperature: -30°C ~ +100°C
Working medium: mineral hydraulic oils and emulsions

OE References:

Komatsu 707-51-12030

Suitable for:

Buldozers/ Булдозери:

D475A-2D475A-3D475A-3-HDD475A-3-SCD475A-5D475A-5AD475A-5E0D475ASD-5E0D575A-2D575A-3D575A-3-M

Compactors/Уплътняващи машини:

WF550-3D

Exavators /Багери:

PC200-7-AAPC210-7KPC210LC-7KPC210NLC-7KPC220LL-8PC228US-3PC228US-3E0PC228USLC-3PC228USLC-3E0PC230NHD-7KPC240-6KPC240LC-6KPC240LC-8KPC240NLC-6KPC240NLC-8KPC290LC-6KPC290NLC-6KPC400PC400-5PC400-5CPC400-5DPC400-6PC400-6ZPC400-7PC400-7-M1PC400-7E0PC400-8PC400HD-5KPC400LCPC400LC-5PC400LC-6PC400LC-6LC/HD-6LCPC400LC-6LK/HD-6LKPC400LC-6LM/HD-6LMPC400LC-6ZPC400LC-7PC400LC-7-M1PC400LC-7E0PC400LC-7LPC400LC-8PC400LCSE-8RPC400ST-6PC400ST-6LCPC410-5PC410LC-5PC450-6KPC450-6K-JPC450-6K-KEPC450-7PC450-7-M1PC450-7KPC450-7K-E0PC450-8PC450LC-6KPC450LC-6K-JPC450LC-6K-KEPC450LC-7PC450LC-7-M1PC450LC-7KPC450LC-7K-E0PC450LC-8PC450LC-8K HIGH REACH DEMOLITIONPC450LCHD-8PC460LC-8PC490LC-10PC600-6PC600-6APC600-6A-KJPC600-6KPC600-6KJPC600-7PC600-7-M1PC600-7KPC600-8PC600-8RPC600LC-6PC600LC-6APC600LC-6A-KJPC600LC-6KPC600LC-6KJPC600LC-7PC600LC-7-M1PC600LC-7KPC600LC-8PC600LC-8RPC650-6PC650-6APC650-7-M1PC650LC-6PC650LC-6APC650LC-7-M1PC650LC-8E0PC700LC-8E0PC750-6PC750-6-AMPC750-7PC750-7-M1PC750LC-6PC750LC-6K-01PC750LC-7PC750LC-7KPC750SE-6PC750SE-6-AMPC750SE-6KPC750SE-6K-01PC750SE-6K-JPC750SE-7PC750SE-7-M1PC750SE-7KPC800-6PC800-6-AMPC800-7PC800-7-M1PC800-8KPC800LC-8PC800LC-8KPC800SE-6PC800SE-6-AMPC800SE-7PC800SE-7-M1PC800SE-8PC800SE-8RPC850-8PC850-8RPC850SE-8PC850SE-8RPW200-7PW200-7E0PW200-7KPW200-7K-KAPW220-7E0PW220-7HPW220-7KPW220-7K-KAPC228USLC-8PC400-8RPC400LC-8RPC450-8RPC450LC-8RPC550LC-8PC600-8E0PC600-8R1PC600LC-8E0PC600LC-8R1PC700LC-8RPC800-8E0PC800LC-8E0PC800LC-8R1PC800SE-8E0PC800SE-8R1PC850-8E0PC850-8R1PC850SE-8E0PC850SE-8R1

Wheel Loaders/ Колесни товарачи:

WA400-1WA420-3MCWA450-5LWA470-5WA480-5WA480-5LWA500-1WA500-1LWA500-1LCWA500-1LEWA500-3WA500-3HWA500-3LWA500-3LKWA500-6 WA500-6WA500-6R



Manufacturer:

​For delivery options to your country, please do not hesitate to contact us!







Product data

The IUY rod seal kit consists of two products:

1/IUW / IUW2 boot made of NBR85 (specification WYS A9516)

Ød=65 mm; ØD=78 mm; h=10 mm

2/ BRDW support ring made of Polyamide (Nylon) PA6 + MoS₂ + Impact Modifier Y7116

Ød=65 mm; ØD=78 mm; t=3 mm

The material PA6 + MoS₂ + Impact Modifier Y7116 is a high-tech, modified Polyamide 6 (Nylon), designed for components subjected to extreme mechanical loads. Thanks to the added molybdenum disulfide (MoS₂), the part has self-lubricating properties and an extremely low coefficient of friction. The built-in impact modifier Y7116 provides high toughness of the material, protecting it from cracking and breaking under heavy hydraulic peaks, vibrations and operation in conditions of low winter temperatures.

Overall product dimensions:

Ød=65 mm; ØD=78 mm; h+t=13 mm

Application range (the following limit values ​​must not be present at the same time):

Pressure: ≤ 300 bar
Speed: ≤ 0.03~1.0 m/s
Temperature: -30°C ~ +100°C
Working medium: mineral hydraulic oils and emulsions

OE References:

Komatsu 707-51-65030, 707-51-65211

Suitable for:

Buldozers/ Булдозери:

D41E-6D41E-6KD41P-6D41P-6KD61EX-15D61EX-15E0-BWD61PX-15D61PX-15E0-BWD65EX-12D65EX-12UD65EX-15D65EX-15E0D65EX-16D65P-12D65PX-12D65PX-12UD65PX-15D65PX-15E0D65PX-16D65WX-15D65WX-15E0D65WX-16D85ESS-2D85ESS-2AD85EX-15D85EX-15E0D85EX-15RD85PX-15D85PX-15E0D85PX-15R

Compactors/Уплътняващи машини:

WF450T-1WF450T-1AWF450T-3

Exavators /Багери:

PC100-3PC100-5PC100-5CPC100-5SPC100-5ZPC100-6PC100-6EPC100-6SPC100-6ZPC100L-3PC100L-5PC100L-6PC100N-6PC100S-3PC100SS-3PC118MR-8PC120-3PC120-5PC120-5CPC120-5KPC120-5MPC120-5SPC120-5XPC120-5ZPC120-6PC120-6EPC120-6E0PC120-6E0-T2PC120-6HPC120-6JPC120-6SPC120-6ZPC120-6Z-A1PC120LC-6PC120LC-6E0PC120S-3PC120SS-3PC128US-1PC128US-2PC128US-2-APC128US-2-ACPC128US-2-ATPC128UU-1PC130-5PC130-5SPC130-6PC130-6EPC130-6E0-T2PC130-6GPC130-6KPC130-7PC130-7KPC130-8PC130F-7PC138US-2PC138US-2-APC138US-2-ACPC138US-2-ATPC138US-2EPC138US-8PC138USLC-2PC138USLC-8PC150LGP-6KPC158US-2PC158USLC-2PC200-5PC200-5/LC-5PC200-5CPC200-5SPC200-5XPC200-5ZPC200-7PC200LC-5PC200LC-5CPC200LC-5SPC200LC-5XPC200LC-7PC220-5PC220-5CPC220LC-5PC220LC-5CPC220LC-7PC220LC-7-BAPC228USLC-1PC228USLC-2PC228USLC-3-AAPC228USLC-3-YAPC228UU-1-MOPC60-6PC60-6CPC60-6SPC60-6ZPC60-7PC60-7-BPC60-7EPC60-7E-BPC60-7SPC60-7S-BPC60L-6PC70-6PC70-6SPC70-7PC70-7-BPC70-7EPC70-7E-BPW118MR-8PW128UU-1PW130-6KPW130-7KPW130ES-6KPW140-7PW148-8PW150ES-6KPW160-7PW160-7E0PW160-8

Wheel Loaders/ Колесни товарачи:

WA200-1WA200-5WA200-5-SNWA200-5-SSWA200-5LWA200-6 HighliftWA200-6WA200L-5WA200PT-5WA200PT-5LWA200PTL-5

Graders/ Грейдери:

GD755-5R

Manufacturer:

​For delivery options to your country, please do not hesitate to contact us!



Product data

The IUY rod seal kit consists of two products:

1/IUW / IUW2 boot made of NBR85 (specification WYS A9516)

Ød=95 mm; ØD=110 mm; h=10 mm

2/ BRDW support ring made of Polyamide (Nylon) PA6 + MoS₂ + Impact Modifier Y7116

Ød=95 mm; ØD=110 mm; t=3 mm

The material PA6 + MoS₂ + Impact Modifier Y7116 is a high-tech, modified Polyamide 6 (Nylon), designed for components subjected to extreme mechanical loads. Thanks to the added molybdenum disulfide (MoS₂), the part has self-lubricating properties and an extremely low coefficient of friction. The built-in impact modifier Y7116 provides high toughness of the material, protecting it from cracking and breaking under heavy hydraulic peaks, vibrations and operation in conditions of low winter temperatures.

Overall product dimensions:

Ød=95 mm; ØD=110 mm; h+t=13 mm

Application range (the following limit values ​​must not be present at the same time):

Pressure: ≤ 300 bar
Speed: ≤ 0.03~1.0 m/s
Temperature: -30°C ~ +100°C
Working medium: mineral hydraulic oils and emulsions

OE References:

Komatsu 707-51-95030,707-51-95211

Suitable for:

Compactors/Уплътняващи машини:

WF450-3

Exavators /Багери:

PC200-3PC200-5PC200-5/LC-5PC200-5CPC200-5SPC200-5TPC200-5XPC200-5ZPC200-6PC200-6 Serial NO.60001 and up, PC200LC-6 Serial NO.70001 and upPC200-6B / PC200LC-6B HYDRAULIC EXCAVATORPC200-6HPC200-6JPC200-6L/LC-6LPC200-6LC/LC-6LCPC200-6SPC200-6S,PC200LC-6S PC200-6ZPC200-7PC200-7-AAPC200-7-APPC200-7/PC200LC-7PC200-8 / PC200LC-8PC200-8PC200CA-6PC200EL-6KPC200EN-6KPC200LC-3PC200LC-5PC200LC-5CPC200LC-5SPC200LC-5TPC200LC-5XPC200LC-6PC200LC-6HPC200LC-6JPC200LC-6LEPC200LC-6SPC200LC-6ZPC200LC-7PC200LC-7-BAPC200LC-7-BPPC200LC-7BPC200LC-7LPC200LC-8PC200LL-7LPC200LL-8PC200SC-6PC200SC-7-M1PC200Z-6LEPC210-5KPC210-6PC210-6DPC210-6GPC210-6KPC210-7-CAPC210-7-CGPC210-7KPC210-8KPC210LC-5KPC210LC-6PC210LC-6GPC210LC-6KPC210LC-6LPC210LC-6LCPC210LC-6LEPC210LC-7-DAPC210LC-7-DGPC210LC-7KPC210LC-8KPC210MH-8PC210NLC-7KPC210NLC-8KPC220-3PC220-5PC220-5CPC220-6 Serial NO.80001 and up, PC220LC-6 Serial NO.90001 and up, PC220SE-6 Serial NO.A0001 and upPC220LC-3PC220LC-5PC220LC-5CPC220LC-7PC220LC-7LPC220LC-8PC220LL-7LPC220LL-8PC228US-1PC228US-1-TNPC228US-1TPC228US-2PC228US-2JPC228US-3PC228US-3-AAPC228US-3-ABPC228US-3-AGPC228US-3-APPC228US-3-YAPC228US-3-YBPC228US-3-YGPC228US-3-YPPC228US-3E0PC228US-3N-YAPC228US-3N-YBPC228US-3N-YPPC228US-3T-YTPC228US-3UPC228USLC-1PC228USLC-1-TNPC228USLC-2PC228USLC-2JPC228USLC-3PC228USLC-3-AAPC228USLC-3-ABPC228USLC-3-APPC228USLC-3-YAPC228USLC-3-YBPC228USLC-3-YPPC228USLC-3E0PC228USLC-3N-YAPC228USLC-3N-YBPC228USLC-3N-YPPC228USLC-3SPC228USLC-3T-YTPC228USLC-3UPC228UU-1PC228UU-1-MOPC228UU-1-TNPC230NHD-7KPC230NHD-8KPC240-5KPC240-6KPC240-8KPC240LC-10PC240LC-5KPC240LC-6KPC240LC-7KPC240LC-8KPC240NLC-5KPC240NLC-6KPC240NLC-7KPC240NLC-8KPC400PC400-5PC400-5CPC400-6PC400-6ZPC400-7PC400-7-M1PC400-7E0PC400LCPC400LC-5PC400LC-6PC400LC-6ZPC400LC-7PC400LC-7-M1PC400LC-7E0PC400ST-6PC400ST-6LCPC410-5PC410LC-5PF5-1PF5LC-1PW200-1PW200-7PW200-7E0PW200-7KPW200-7K-KAPW210-1PW220-7E0PW220-7HPW220-7KPW220-7K-KAHB205-1HB215LC-1PC200-8E0PC200LC-8E0PC228US-8PC228USLC-8PC240LC-8PC240NLC-10PC400-8PC400-8RPC400LC-8PC400LC-8R

Others/ Други:

BP500-3BP500-7-M1

Wheel Loaders/ Колесни товарачи:

WA430-6WA430-6E0WA450-1WA450-2WA450-3WA450-3-HWA450-3-XWA450-3AWA450-3A-SWA450-3A-TNWA450-3MCWA450-5LWA450-6WA450-6-W1WA450L-3WA470-1WA470-3 activeWA470-3 ActiveWA470-3WA470-5WA470-6 LCWA470-6WA470-6AWA470-DZ-3 Serial No.20118 and upWA480-5WA480-5LWA480-6 LCWA480-6

Manufacturer:

​For delivery options to your country, please do not hesitate to contact us!



Product data

The IUY rod seal kit consists of two products:

1/IUW / IUW2 boot made of NBR85 (specification WYS A9516)

Ød=110 mm; ØD=130 mm; h=10 mm

2/ BRDW support ring made of Polyamide (Nylon) PA6 + MoS₂ + Impact Modifier Y7116

Ød=110 mm; ØD=130 mm; t=3 mm

The material PA6 + MoS₂ + Impact Modifier Y7116 is a high-tech, modified Polyamide 6 (Nylon), designed for components subjected to extreme mechanical loads. Thanks to the added molybdenum disulfide (MoS₂), the part has self-lubricating properties and an extremely low coefficient of friction. The built-in impact modifier Y7116 provides high toughness of the material, protecting it from cracking and breaking under heavy hydraulic peaks, vibrations and operation in conditions of low winter temperatures.

Overall product dimensions:

Ød=110 mm; ØD=130 mm; h+t=13 mm

Application range (the following limit values ​​must not be present at the same time):

Pressure: ≤ 300 bar
Speed: ≤ 0.03~1.0 m/s
Temperature: -30°C ~ +100°C
Working medium: mineral hydraulic oils and emulsions

OE References:

Komatsu 707-51-11030

Suitable for:

Buldozers/ Булдозери:

D155A-5D155A-6D155A-6RD155AX-5D155AX-6D155AX-6AD85EX-15D85EX-15E0D85EX-15RD85MS-15D85PX-15D85PX-15E0D85PX-15R

Compactors/Уплътняващи машини:

WF450T-1WF450T-1AWF450T-3

Crawler Loaders/ Верижни товарачи:

D85MS-15

Drum Trucks/Самосвали:

HD1500-7

Exavators /Багери:

PC100-3PC100-5PC100-5CPC100-5SPC100-5ZPC100-6PC100-6EPC100-6SPC100-6ZPC100L-3PC100L-5PC100L-6PC100S-3PC100SS-3PC120-3PC120-5PC120-5CPC120-5KPC120-5MPC120-5SPC120-5XPC120-5ZPC120-6PC120-6EPC120-6E0PC120-6E0-T2PC120-6HPC120-6JPC120-6SPC120-6ZPC120-6Z-A1PC120LC-6PC120LC-6E0PC120S-3PC120SC-6PC120SS-3PC128US-1PC128US-2PC128US-2-APC128US-2-ACPC128US-2-ATPC128UU-1PC128UU-2PC130-5PC130-5KPC130-5SPC130-6PC130-6EPC130-6E0-T2PC130-6GPC130-6KPC130-7PC130-7KPC130-8PC130F-7PC138US-2PC138US-2-APC138US-2-ACPC138US-2-ATPC138US-2EPC138US-8PC138USLC-2PC138USLC-8PC150-5PC150-6KPC150HD-5KPC150LC-6KPC150LGP-6KPC150NHD-5KPC158US-2PC158USLC-2PC160-6KPC160LC-7PC160LC-7-E0 (KA SPEC.)PC160LC-7E0PC160LC-7KPC160LC-7K-KAPC160LC-8PC180LC-5KPC180LC-6KPC180LC-7-E0PC180LC-7KPC180LLC-5KPC180NLC-5KPC180NLC-6KPC180NLC-7-E0PC180NLC-7KPC195LC-8PC200-3PC200EL-6KPC200EN-6KPC200LC-3PF5-1PF5LC-1PW128UU-1PW130-6KPW130-7KPW130ES-6KPW140-7PW148-8PW150ES-6KPW160-7PW160-7E0PW160-7KPW170-5KPW170ES-6KPW170ES-6K-KAPW180-7E0PW200-1PW210-1PW160-8

Others/ Други:

BP500-3



Wheel Dozers/Колесни булдозери:

WD600-3

Wheel Loaders/ Колесни товарачи:

WA200-1WA200-3WA200-3-XWA250-1WA250-1LCWA250-3WA250-3-SNWA250-3LWA250-3MCWA250-5WA250-5LWA250-6 HighliftWA250-6WA250L-3WA250L-5WA270-5WA270-5-SNWA300-1WA300-3AWA300-3A-SNWA300-3A-XWA300-3CSWA300L-3WA320 AVANCE CUSTOM Serial No.20001 and upWA320-1WA320-1LCWA320-3 activeWA320-3WA320-3CSWA320-3LWA320-3MCWA320-5WA320-5LWA320-6 HighliftWA320-6WA320L-5WA320PT-5LWA320PZ-6



Manufacturer:

​For delivery options to your country, please do not hesitate to contact us!







Product data

The IUY rod seal kit consists of two products:

1/IUW / IUW2 boot made of NBR85 (specification WYS A9516)

Ød=75 mm; ØD=88 mm; h=10 mm

2/ BRDW support ring made of Polyamide (Nylon) PA6 + MoS₂ + Impact Modifier Y7116

Ød=75 mm; ØD=88 mm; t=3 mm

The material PA6 + MoS₂ + Impact Modifier Y7116 is a high-tech, modified Polyamide 6 (Nylon), designed for components subjected to extreme mechanical loads. Thanks to the added molybdenum disulfide (MoS₂), the part has self-lubricating properties and an extremely low coefficient of friction. The built-in impact modifier Y7116 provides high toughness of the material, protecting it from cracking and breaking under heavy hydraulic peaks, vibrations and operation in conditions of low winter temperatures.

Overall product dimensions:

Ød=75 mm; ØD=88 mm; h+t=13 mm

Application range (the following limit values ​​must not be present at the same time):

Pressure: ≤ 300 bar
Speed: ≤ 0.03~1.0 m/s
Temperature: -30°C ~ +100°C
Working medium: mineral hydraulic oils and emulsions

OE References:

Komatsu 707-51-75030, 707-51-75211

Suitable for:

Buldozers/ Булдозери:

D155A-5D155A-6D155A-6RD155AX-5D155AX-6D155AX-6AD85EX-15D85EX-15E0D85EX-15RD85MS-15D85PX-15D85PX-15E0D85PX-15R

Compactors/Уплътняващи машини:

WF450T-1WF450T-1AWF450T-3

Crawler Loaders/ Верижни товарачи:

D85MS-15

Drum Trucks/Самосвали:

HD1500-7

Exavators /Багери:

PC100-3PC100-5PC100-5CPC100-5SPC100-5ZPC100-6PC100-6EPC100-6SPC100-6ZPC100L-3PC100L-5PC100L-6PC100S-3PC100SS-3PC120-3PC120-5PC120-5CPC120-5KPC120-5MPC120-5SPC120-5XPC120-5ZPC120-6PC120-6EPC120-6E0PC120-6E0-T2PC120-6HPC120-6JPC120-6SPC120-6ZPC120-6Z-A1PC120LC-6PC120LC-6E0PC120S-3PC120SC-6PC120SS-3PC128US-1PC128US-2PC128US-2-APC128US-2-ACPC128US-2-ATPC128UU-1PC128UU-2PC130-5PC130-5KPC130-5SPC130-6PC130-6EPC130-6E0-T2PC130-6GPC130-6KPC130-7PC130-7KPC130-8PC130F-7PC138US-2PC138US-2-APC138US-2-ACPC138US-2-ATPC138US-2EPC138US-8PC138USLC-2PC138USLC-8PC150-5PC150-6KPC150HD-5KPC150LC-6KPC150LGP-6KPC150NHD-5KPC158US-2PC158USLC-2PC160-6KPC160LC-7PC160LC-7-E0 (KA SPEC.)PC160LC-7E0PC160LC-7KPC160LC-7K-KAPC160LC-8PC180LC-5KPC180LC-6KPC180LC-7-E0PC180LC-7KPC180LLC-5KPC180NLC-5KPC180NLC-6KPC180NLC-7-E0PC180NLC-7KPC195LC-8PC200-3PC200EL-6KPC200EN-6KPC200LC-3PF5-1PF5LC-1PW128UU-1PW130-6KPW130-7KPW130ES-6KPW140-7PW148-8PW150ES-6KPW160-7PW160-7E0PW160-7KPW170-5KPW170ES-6KPW170ES-6K-KAPW180-7E0PW200-1PW210-1PW160-8

Wheel Loaders/ Колесни товарачи:

WA200-1WA200-3WA200-3-XWA250-1WA250-1LCWA250-3WA250-3-SNWA250-3LWA250-3MCWA250-5WA250-5LWA250-6 HighliftWA250-6WA250L-3WA250L-5WA270-5WA270-5-SNWA300-1WA300-3AWA300-3A-SNWA300-3A-XWA300-3CSWA300L-3WA320 AVANCE CUSTOM Serial No.20001 and upWA320-1WA320-1LCWA320-3 activeWA320-3WA320-3CSWA320-3LWA320-3MCWA320-5WA320-5LWA320-6 HighliftWA320-6WA320L-5WA320PT-5LWA320PZ-6

Wheel Dozers/Колесни булдозери:

WD600-3

Manufacturer:

​For delivery options to your country, please do not hesitate to contact us!



Product data

The IUY rod seal kit consists of two products:

1/IUW / IUW2 boot made of NBR85 (specification WYS A9516)

Ød=85 mm; ØD=100 mm; h=10 mm

2/ BRDW support ring made of Polyamide (Nylon) PA6 + MoS₂ + Impact Modifier Y7116

Ød=85 mm; ØD=100 mm; t=3 mm

The material PA6 + MoS₂ + Impact Modifier Y7116 is a high-tech, modified Polyamide 6 (Nylon), designed for components subjected to extreme mechanical loads. Thanks to the added molybdenum disulfide (MoS₂), the part has self-lubricating properties and an extremely low coefficient of friction. The built-in impact modifier Y7116 provides high toughness of the material, protecting it from cracking and breaking under heavy hydraulic peaks, vibrations and operation in conditions of low winter temperatures.

Overall product dimensions:

Ød=85 mm; ØD=100 mm; h+t=13 mm

Application range (the following limit values ​​must not be present at the same time):

Pressure: ≤ 300 bar
Speed: ≤ 0.03~1.0 m/s
Temperature: -30°C ~ +100°C
Working medium: mineral hydraulic oils and emulsions

OE References:

Komatsu 707-51-85030, 707-51-85211

Suitable for:

Cranes/Кранове:

LW100-1X

Exavators /Багери:

PC120-6PC120-6E0-T2PC150-5PC150-6KPC150LC-6KPC160-6KPC160LC-7PC160LC-7-E0 (KA SPEC.)PC160LC-7KPC160LC-7K-KAPC160LC-8PC180LC-5KPC180LC-6KPC180LC-7-E0PC180LC-7KPC180LLC-5KPC180NLC-5KPC180NLC-6KPC180NLC-7-E0PC180NLC-7KPC195LC-8PC200-3PC200-5PC200-5/LC-5PC200-5CPC200-5SPC200-5TPC200-5XPC200-5ZPC200-6PC200-6 Serial NO.60001 and up, PC200LC-6 Serial NO.70001 and upPC200-6B / PC200LC-6B HYDRAULIC EXCAVATORPC200-6HPC200-6JPC200-6L/LC-6LPC200-6LC/LC-6LCPC200-6SPC200-6S,PC200LC-6S PC200-6ZPC200-7PC200-7-AAPC200-7-APPC200-7/PC200LC-7PC200-8 / PC200LC-8PC200-8PC200CA-6PC200EL-6KPC200EN-6KPC200LC-3PC200LC-5PC200LC-5CPC200LC-5SPC200LC-5TPC200LC-5XPC200LC-6PC200LC-6HPC200LC-6JPC200LC-6LEPC200LC-6SPC200LC-6ZPC200LC-7PC200LC-7-BAPC200LC-7-BPPC200LC-8PC200LL-6PC200SC-6PC200SC-7-M1PC200Z-6LEPC210-5KPC210-6PC210-6DPC210-6GPC210-6KPC210-7-CAPC210-7-CGPC210-7KPC210-8KPC210LC-5KPC210LC-6PC210LC-6GPC210LC-6KPC210LC-7-DAPC210LC-7-DGPC210LC-7KPC210LC-8KPC210NLC-7KPC210NLC-8KPC220-5PC220-8PC220LC-5PC220LC-8PC220LL-6PC228US-1PC228US-1-TNPC228US-1TPC228US-2PC228US-2JPC228US-3PC228US-3-AAPC228US-3-ABPC228US-3-AGPC228US-3-APPC228US-3-YAPC228US-3-YBPC228US-3-YGPC228US-3-YPPC228US-3E0PC228US-3N-YAPC228US-3N-YBPC228US-3N-YPPC228US-3T-YTPC228US-3UPC228USLC-1PC228USLC-1-TNPC228USLC-2PC228USLC-2JPC228USLC-3PC228USLC-3-AAPC228USLC-3-ABPC228USLC-3-APPC228USLC-3-YAPC228USLC-3-YBPC228USLC-3-YPPC228USLC-3E0PC228USLC-3N-YAPC228USLC-3N-YBPC228USLC-3N-YPPC228USLC-3T-YTPC228USLC-3UPC228UU-1-MOPC228UU-1-TNPC230NHD-7KPC230NHD-8KPC600-8PC600LC-8PC650LC-8E0PC800LC-8PW128UU-1PW170-5KPW170ES-6KPW170ES-6K-KAPW180-7E0PW180-7KPW200-1PW200-7PW200-7E0PW200-7KPW210-1PW220-7E0PW220-7HHB205-1HB215LC-1PC190LC-8PC190NLC-8PC200-8E0PC200LC-8E0PC228US-8PC228USLC-8PC600-8E0PC600LC-8E0PC800LC-8E0PW180-10

Others/ Други:

BP500-3BP500-7-M1

Wheel Loaders/ Колесни товарачи:

WA350-1

Manufacturer:

​For delivery options to your country, please do not hesitate to contact us!



Product data

The IUY rod seal kit consists of two products:

1/IUW / IUW2 boot made of NBR85 (specification WYS A9516)

Ød=100 mm; ØD=115 mm; h=10 mm

2/ BRDW support ring made of Polyamide (Nylon) PA6 + MoS₂ + Impact Modifier Y7116

Ød=100 mm; ØD=115 mm; t=3 mm

The material PA6 + MoS₂ + Impact Modifier Y7116 is a high-tech, modified Polyamide 6 (Nylon), designed for components subjected to extreme mechanical loads. Thanks to the added molybdenum disulfide (MoS₂), the part has self-lubricating properties and an extremely low coefficient of friction. The built-in impact modifier Y7116 provides high toughness of the material, protecting it from cracking and breaking under heavy hydraulic peaks, vibrations and operation in conditions of low winter temperatures.

Overall product dimensions:

Ød=100 mm; ØD=115 mm; h+t=13 mm

Application range (the following limit values ​​must not be present at the same time):

Pressure: ≤ 300 bar
Speed: ≤ 0.03~1.0 m/s
Temperature: -30°C ~ +100°C
Working medium: mineral hydraulic oils and emulsions

OE References:

Hitachi 4168227,Komatsu 707-51-10030, 707-51-10130, 707-51-10211

Suitable for:

HITACHI

EX200-3, EX210H-5 JPN, EX210LC-5HHE, EX220, EX220-2, EX220-3, EX220-5, EX220-5 JPN, EX230-5, EX230H-5 JPN, EX230K-5, EX270-5, EX280H-5, EX300, EX300-2, EX300-3, EX300-3C, EX310H-3C, RX2000

KOMATSU

Buldozers/ Булдозери:

D155A-6D155A-6RD155AX-6D155AX-6AD275A-5D275A-5RD275AX-5D275AX-5-KOD275AX-5E0

Compactors/Уплътняващи машини:

WF450-3

Exavators /Багери:

PC150-6KPC150LC-6KPC160-6KPC160LC-7KPC1800-6PC180LC-6KPC180NLC-6KPC200-7PC200EL-6KPC200EN-6KPC200LC-7PC210-8KPC210LC-8KPC210NLC-8KPC220-5PC220-5CPC220-6PC220-6 Serial NO.80001 and up, PC220LC-6 Serial NO.90001 and up, PC220SE-6 Serial NO.A0001 and upPC220-6ZPC220-7PC220-7 Serial NO.DBH0001 and up, PC220LC-7 Serial NO.DBJ0001 and upPC220-7-AAPC220-8PC220LC-5PC220LC-5CPC220LC-6PC220LC-6LPC220LC-6LCPC220LC-6LEPC220LC-6ZPC220LC-7PC220LC-7-BAPC220LC-7LPC220LC-8PC220LL-7LPC220LL-8PC228US-1PC228US-1-TNPC228US-2PC228US-3PC228US-3-YAPC228US-3-YBPC228US-3E0PC228USLC-1-TNPC228USLC-3PC228USLC-3E0PC230-6PC230-7-AAPC230-7-CGPC230LC-6PC230LC-7-BAPC230LC-7-DGPC230NHD-8KPC240-5KPC240-6KPC240-8KPC240LC-5KPC240LC-6KPC240LC-7KPC240LC-8KPC240LC/NLC-10 DEMOLITIONPC240NLC-5KPC240NLC-6KPC240NLC-7KPC240NLC-8KPC250-6PC250HD-6ZPC250LC-6PC250LC-6LPC250LC-6LCPC250LC-6LEPC270-7PC270-7-AGPC270-8PC270LC-6LEPC270LC-7LPC270LC-8PC270LC-8-W1PC270LC-8N1-W1PC270LL-7LPC290-8KPC290LC-10PC290LC-6KPC290LC-7KPC290LC-8KPC290LC/NLC-10 DEMOLITIONPC290LC/NLC-8 HIGH REACH DEMOLITIONPC290NLC-6KPC290NLC-7KPC290NLC-8KPC300PC300-5PC300-5CPC300-5KPC300-6PC300-6 SERIAL NUMBERS:J10295PC300-6ZPC300-7PC300-7 SERIAL NUMBERS : J20001-UPPC300-7-AAPC300-7E0PC300-8PC300HD-5KPC300HD-7E0PC300HD-7LPC300HD-8 s/n A87001 and upPC300LCPC300LC-5PC300LC-5KPC300LC-5LCPC300LC-6PC300LC-6LC/HD-6LC/HD-6MHPC300LC-6LE/HD-6LEPC300LC-6ZPC300LC-7PC300LC-7-BAPC300LC-7E0PC300LC-7LPC300LC-8PC300LL-7E0PC300LL-7LPC300NLC-5KPC300SC-6PC308USLC-3PC308USLC-3E0-W1PC310-5PC310LC-5PC340-6KPC340LC-6KPC340LC-6K-JPC340LC-7KPC340LC-7K-E0PC340NLC-6PC340NLC-6KPC340NLC-7KPC340NLC-7K-E0PC350-6PC350-6ZPC350-7PC350-7-AAPC350-7E0PC350-8PC350HD-8PC350LC-6PC350LC-6ZPC350LC-7PC350LC-7-BAPC350LC-7E0PC350LC-8PC350LC/NLC-8 DEMOLITIONPC350LC/NLC-8K HIGH REACH DEMOLITION (23 M)PC350LL-7E0PC350NLC-8PC360-7PC360LC-10PC360LC/NLC-10 DEMOLITIONPC380LC-6KPC380LC-6K-JPC380LC-7KPC390LC-10PC390LL-10 A50601 & UPPC400-7PC400-7 SERIAL NUMBERS : J20001-UPPC400-7-M1PC400LC-7PC400LC-7-M1PC400LC-7LPC450-7PC450-7-M1PC450-7KPC450LC-7PC450LC-7-M1PC450LC-7KPC450LC-8K HIGH REACH DEMOLITIONPW150ES-6KPW160-7PW160-7E0PW160-7KPW170ES-6KPW170ES-6K-KAPW180-7E0PW180-7KPW220-7E0PW220-7HPC160LC-8PC190LC-8PC190NLC-8PC200LC-8PC228US-8PC228USLC-8PC240LC-8PC290NLC-10PC308USLC-3E0PC360NLC-10PW160-8PW180-10

Wheel Loaders/ Колесни товарачи:

WA250PZ-5WA250PZ-6WA320PT-5LWA320PZ-6WA350-1WA350-3A-SWA380-5WA380-5-SNWA380-5LWA380-6WA380Z-6WA400-1WA400-3-HWA400-3-XWA400-3AWA400-3A-SWA400-3A-SNWA400-5LWA420-1WA420-3 activeWA420-3WA420-3CSWA420-3LWA420-3MCWA420-DZ-3 Serial No.10001 and upWA430-5WA430-6WA450-1WA450-2WA450-3WA450-3-HWA450-3-XWA450-3AWA450-3A-SWA450-3MCWA450-5LWA450-6WA450-6-W1WA450L-3WA470-1WA470-3 activeWA470-3 ActiveWA470-3WA470-5WA470-6 LCWA470-6WA470-6AWA470-DZ-3 Serial No.20118 and up



Manufacturer:

​For delivery options to your country, please do not hesitate to contact us!





Product data

The IUY rod seal kit consists of two products:

1/IUW / IUW2 boot made of NBR85 (specification WYS A9516)

Ød=70 mm; ØD=83 mm; h=10 mm

2/ BRDW support ring made of Polyamide (Nylon) PA6 + MoS₂ + Impact Modifier Y7116

Ød=70 mm; ØD=83 mm; t=3 mm

The material PA6 + MoS₂ + Impact Modifier Y7116 is a high-tech, modified Polyamide 6 (Nylon), designed for components subjected to extreme mechanical loads. Thanks to the added molybdenum disulfide (MoS₂), the part has self-lubricating properties and an extremely low coefficient of friction. The built-in impact modifier Y7116 provides high toughness of the material, protecting it from cracking and breaking under heavy hydraulic peaks, vibrations and operation in conditions of low winter temperatures.

Overall product dimensions:

Ød=70 mm; ØD=83 mm; h+t=13 mm

Application range (the following limit values ​​must not be present at the same time):

Pressure: ≤ 300 bar
Speed: ≤ 0.03~1.0 m/s
Temperature: -30°C ~ +100°C
Working medium: mineral hydraulic oils and emulsions

OE References:

Komatsu 707-51-60030, 707-51-60060, 707-51-60211

Suitable for:

Backhoe Loaders/Багер-товарачи:

WB91R-5WB91R-5E0WB93R-5WB93R-5E0WB93S-5E0WB97R-5WB97R-5E0WB97S-5E0

Buldozers/ Булдозери:

D41E-6D61E-12D61EX-12D61EX-12A-WD61PX-12D61PX-12A-WD65EX-16D65PX-16D65WX-16

Compactors/Уплътняващи машини:

WF550T-3WF550T-3AWF550T-3DWF600T-1

Crawler Loaders/ Верижни товарачи:

D68ESS-12

Exavators /Багери:

PC100-5PC100-5CPC100-5SPC100-5ZPC100-6PC100-6EPC100-6SPC100-6ZPC100L-5PC100L-6PC118MR-8PC120-6PC120-6E0-T2PC120-6HPC120-6JPC120-6SPC120-6ZPC128UU-1PC128UU-2PC130F-7PC138US-8PC60-6PC60-6CPC60-6SPC60-6ZPC60-7PC60-7-BPC60-7EPC60-7E-BPC60-7SPC60-7S-BPC60L-6PC70-6PC70-6SPC70-7PC70-7-BPC70-7EPC70-7E-BPW118MR-8PW128UU-1PW98MR-6PW98MR-8

Wheel Loaders/ Колесни товарачи:

WA100-1WA100SS-1WA100SSS-1WA120-3WA150-1WA150-3WA150-3-SNWA150-3-XWA150-5WA150-5-AWA150-5-CNWA150-5-SSWA150-5-TKWA150-6WA150L-5WA150PZ-5WA150PZ-6WA180-3WA180L-3WA200-1WA200-3-XWWA250PT-3WA250PT-3LWA270PT-3 activeWA300-1WA300-3A-SNWA500-6 WA500-6WR11-1WR11-3WR11SS-1WA500-6R



Manufacturer:

​For delivery options to your country, please do not hesitate to contact us!





Product data

The IUY rod seal kit consists of two products:

1/IUW / IUW2 boot made of NBR85 (specification WYS A9516)

Ød=50 mm; ØD=63 mm; h=10 mm

2/ BRDW support ring made of Polyamide (Nylon) PA6 + MoS₂ + Impact Modifier Y7116

Ød=50 mm; ØD=63 mm; t=3 mm

The material PA6 + MoS₂ + Impact Modifier Y7116 is a high-tech, modified Polyamide 6 (Nylon), designed for components subjected to extreme mechanical loads. Thanks to the added molybdenum disulfide (MoS₂), the part has self-lubricating properties and an extremely low coefficient of friction. The built-in impact modifier Y7116 provides high toughness of the material, protecting it from cracking and breaking under heavy hydraulic peaks, vibrations and operation in conditions of low winter temperatures.

Overall product dimensions:

Ød=50 mm; ØD=63 mm; h+t=13 mm

Application range (the following limit values ​​must not be present at the same time):

Pressure: ≤ 300 bar
Speed: ≤ 0.03~1.0 m/s
Temperature: -30°C ~ +100°C
Working medium: mineral hydraulic oils and emulsions

OE References:

Komatsu 707-51-50030, 707-51-50211

Suitable for:

​Backhoe Loaders/Багер-товарачи:

WB142-5WB91R-5WB91R-5E0WB93R-5WB93R-5E0WB93S-5E0WB97R-5WB97R-5E0WB97S-5E0

Buldozers/ Булдозери:

D41E-6D41E-6KD41P-6D41P-6KD41PF-6K-T2

Compactors/Уплътняващи машини:

WF450-3WF450T-1WF450T-1AWF450T-3

Exavators /Багери:

PC400LC-6ZPC57-7

Graders/ Грейдери:

GD755-3GH320-3GD755-5R

Wheel Loaders/ Колесни товарачи:

WA100-3-HWA100-3-HWWA100-3-XWA100-3AWA100-3A-SWA100-3A-SNWA100-5WA100-5-CNWA100-5-SNWA100-5-SSWA100-5-TKWA120-3WA120-3CSWA120-3LWA120L-3WA200-1WA200-3-SNWA200-3-XWWA270-5WA270-5-SNWA300-1WA300-3A-SNWA300-3A-XWWA320-5WA350-1WA350-3A-SNWA350-3A-SWWA380-5WA380-5-SNWA400-1WA400-3A-SWWA430-5WA430-5-SNWA450-1WA450-2WA450-3WA450-3-HWA450-3-XWA450-3AWA450-3A-SWA450-3A-TNWA450-3LWA450-3MCWA450-5LWA450-6WA450-6-W1WA450L-3WA470-1WA470-3 activeWA470-3 ActiveWA470-3WA470-5WA470-6 LCWA470-6WA470-6AWA470-DZ-3 Serial No.20118 and upWA480-5WA480-5LWA480-6 LCWA480-6WA70-1WA80-3WA80-3-CBWA80-5 20 km/hWA80-5 30 km/hWA80-5

Manufacturer:

​For delivery options to your country, please do not hesitate to contact us!





Product data

The IUY rod seal kit consists of two products:

1/IUW / IUW2 boot made of NBR85 (specification WYS A9516)

Ød=70 mm; ØD=83 mm; h=10 mm

2/ BRDW support ring made of Polyamide (Nylon) PA6 + MoS₂ + Impact Modifier Y7116

Ød=70 mm; ØD=83 mm; t=3 mm

The material PA6 + MoS₂ + Impact Modifier Y7116 is a high-tech, modified Polyamide 6 (Nylon), designed for components subjected to extreme mechanical loads. Thanks to the added molybdenum disulfide (MoS₂), the part has self-lubricating properties and an extremely low coefficient of friction. The built-in impact modifier Y7116 provides high toughness of the material, protecting it from cracking and breaking under heavy hydraulic peaks, vibrations and operation in conditions of low winter temperatures.

Overall product dimensions:

Ød=70 mm; ØD=83 mm; h+t=13 mm

Application range (the following limit values ​​must not be present at the same time):

Pressure: ≤ 300 bar
Speed: ≤ 0.03~1.0 m/s
Temperature: -30°C ~ +100°C
Working medium: mineral hydraulic oils and emulsions

OE References:

Komatsu 707-51-70030, 707-51-70211

Suitable for:

Buldozers/ Булдозери:

D61E-12D61EX-12D61EX-15D61EX-15E0-BWD61PX-12D61PX-15D61PX-15E0-BWD65E-12D65EX-12D65EX-15D65EX-15E0D65EX-16D65P-12D65PX-12D65PX-12UD65PX-15D65PX-15E0D65PX-16D65WX-15D65WX-15E0D65WX-16D68ESS-12E0D85ESS-2D85ESS-2AD85ESS-3D85EX-15D85EX-15E0D85EX-15RD85MS-15

Compactors/Уплътняващи машини:

WF600T-1WF650T-3

Cranes/Кранове:

LW100-1H

Crawler Carriers/Верижни претоварачи:

CD110R-2

Crawler Loaders/ Верижни товарачи:

D68ESS-12

Exavators /Багери:

PC100N-6PC118MR-8PC120-3PC120-5PC120-5CPC120-5KPC120-5MPC120-5SPC120-5XPC120-5ZPC120-6PC120-6EPC120-6E0PC120-6E0-T2PC120-6HPC120-6JPC120-6SPC120-6ZPC120-6Z-A1PC120LC-6PC120LC-6E0PC120S-3PC120SC-6PC120SS-3PC128US-1PC128US-2PC128US-2-APC128US-2-ACPC128US-2-ATPC128UU-1PC128UU-2PC130-5PC130-5KPC130-5SPC130-6PC130-6EPC130-6E0-T2PC130-6GPC130-6KPC130-7PC130-7KPC130-8PC130F-7PC138US-2PC138US-2-APC138US-2-ACPC138US-2-ATPC138US-2EPC138US-8PC138USLC-2PC138USLC-8PC150-5PC150HD-5KPC150LC-6KPC150LGP-6KPC150NHD-5KPC158US-2PC158USLC-2PC160-6KPC160LC-7PC160LC-7-E0 (KA SPEC.)PC160LC-7E0PC160LC-7KPC160LC-7K-KAPC160LC-8PC180LC-6KPC180LC-7-E0PC180LC-7KPC180NLC-6KPC180NLC-7-E0PC180NLC-7KPC490LC-10PC60-7PW118MR-8PW128UU-1PW130-6KPW130-7KPW130ES-6KPW140-7PW148-8PW150ES-6KPW160-7PW160-7E0PW160-7KPW180-7KPC190LC-8PC190NLC-8PW160-8PW180-10

Wheel Dozers/Колесни булдозери:

WD500-3WD600-1

Wheel Loaders/ Колесни товарачи:

WA120-1WA120-1LCWA120-3MCWA120L-3WA150-1WA150-3WA150-3-SNWA150-3-XWA150-5WA180-1WA180-1LCWA180-3WA180-3LWA180-3MCWA180L-3WA180PT-3WA200-1WA200-3WA200-3-SNWA200-3-XWA200-3-XWWA200PZ-6WA250-1WA250-1LCWA250-3WA250-3-SNWA250-3LWA250-3MCWA250-5WA250-5LWA250-6 HighliftWA250-6WA250L-3WA250L-5WA250PT-3WA250PT-3LWA250PT-3MCWA250PT-5WA250PT-5LWA250PTL-5WA250PZ-5WA250PZ-6WA270-5WA270-5-SNWA270PT-3 activeWA300-1WA300-3A-SNWA300-3A-XWWA320-5WA350-1WA350-3A-SNWA350-3A-SWWA380-5WA430-6WA450-1WA450-3WA450-3A-STWA450-3A-TNWA470-5WA500-1WA500-1LWA500-1LCWA500-1LEWA500-3

Manufacturer:

​For delivery options to your country, please do not hesitate to contact us!
