Product data

The hydraulic seal UPH has a symmetrical design and is suitable for both piston and rod.

Ød=18 mm ; ØD=25 mm ; h=6.5 mm ; ØD1=  mm ; HA= mm ; HB= mm ; r= mm

Material: NBR90

Application range (the following limit values cannot appear at the same time):

Pressure: ≤ 320 bar; when the pressure is higher than 150 bar, it is recommended to use a back-up ring
Speed: ≤ 0.5 m/s
Temperature: -30°C ~ +100°C
Media: mineral hydraulic oils, water-glycol hydraulic oils, emulsions

Manufacturer:

Zhongxingshun Sealing Products Factory

V-ring seal, VA design.

Manufacturer:

Zhongxingshun Sealing Products Factory

Product data

D=100 mm ; d=85 mm ; H=5.6 mm ; G=6 mm ; D1=99.4 mm ; L=3 mm

Material: NBR 80

Application range (the following limit values cannot appear at the same time):

Pressure: ≤ 10 bar
Speed: ≤ 1 m/s
Temperature: -30°C ~ +80°C
Media: Air, oil-lubricated and dry air, oil-free air (initial lubrication during assembly)

Manufacturer:

Zhongxingshun Sealing Products Factory

Product data

D=80 mm ; d=65 mm ; H=5.6 mm ; G=6 mm ; D1=79.4 mm ; L=3 mm

Material: NBR 80

Application range (the following limit values cannot appear at the same time):

Pressure: ≤ 10 bar
Speed: ≤ 1 m/s
Temperature: -30°C ~ +80°C
Media: Air, oil-lubricated and dry air, oil-free air (initial lubrication during assembly)

Manufacturer:

Zhongxingshun Sealing Products Factory

Product data

D=63 mm ; d=53 mm ; H=3.7 mm ; G=4 mm ; D1=62.4 mm ; L=2.5 mm

Material: NBR 80

Application range (the following limit values cannot appear at the same time):

Pressure: ≤ 10 bar
Speed: ≤ 1 m/s
Temperature: -30°C ~ +80°C
Media: Air, oil-lubricated and dry air, oil-free air (initial lubrication during assembly)

Manufacturer:

Zhongxingshun Sealing Products Factory

Product data

D=50 mm ; d=40 mm ; H=3.7 mm ; G=4 mm ; D1=49.5 mm ; L=2.5 mm

Material: NBR 80

Application range (the following limit values cannot appear at the same time):

Pressure: ≤ 10 bar
Speed: ≤ 1 m/s
Temperature: -30°C ~ +80°C
Media: Air, oil-lubricated and dry air, oil-free air (initial lubrication during assembly)

Manufacturer:

Zhongxingshun Sealing Products Factory

Product data

D=40 mm ; d=32 mm ; H=3 mm ; G=3.2 mm ;D1=39.5 mm ; L=2 mm

Material: NBR 80

Application range (the following limit values cannot appear at the same time):

Pressure: ≤ 10 bar
Speed: ≤ 1 m/s
Temperature: -30°C ~ +80°C
Media: Air, oil-lubricated and dry air, oil-free air (initial lubrication during assembly)

Manufacturer:

Zhongxingshun Sealing Products Factory

Product data

D=32 mm ; d=24 mm ; H=3 mm ; G=3.2 mm ;D1=31.5 mm ; L=2 mm

Material: NBR 80

Application range (the following limit values cannot appear at the same time):

Pressure: ≤ 10 bar
Speed: ≤ 1 m/s
Temperature: -30°C ~ +80°C
Media: Air, oil-lubricated and dry air, oil-free air (initial lubrication during assembly)

Manufacturer:

Zhongxingshun Sealing Products Factory

Product data

D=25 mm ; d=17 mm ; H=3 mm ; G=3.2 mm ;D1=24.5 mm ; L=2 mm

Material: NBR 80

Application range (the following limit values cannot appear at the same time):

Pressure: ≤ 10 bar
Speed: ≤ 1 m/s
Temperature: -30°C ~ +80°C
Media: Air, oil-lubricated and dry air, oil-free air (initial lubrication during assembly)

Manufacturer:

Zhongxingshun Sealing Products Factory

Product data

D=20 mm ; d=14 mm ; H=2.2 mm ; G=2.4 mm ;D1=19.5 mm ; L=1.5 mm

Material: NBR 80

Application range (the following limit values cannot appear at the same time):

Pressure: ≤ 10 bar
Speed: ≤ 1 m/s
Temperature: -30°C ~ +80°C
Media: Air, oil-lubricated and dry air, oil-free air (initial lubrication during assembly)

Manufacturer:

Zhongxingshun Sealing Products Factory
