SPGW Hydraulic Piston Seals
SPGW is a two-way hydraulic piston seal composed a mofified PTFE+bronze element, one rubber seal ring and two anti-withdrawal retaining rings made of polyamide resin. SPGW is a seal for high pressure operation which improves the oil scraping ability of SPG. SPGW type is suitable for forklift arm cylinders, cantilever cylinders, bucket cylinders, bulldozer lifting cylinders, flat shovel cylinders, crane sliding cylinders, hydraulic suspension cylinders, dump trucks, presses, injection molding machines, etc.
Material:
Modified PTFE+bronze, high performance NBR with Shore hardness of 80 and polyamide resin
Scope of application:
Working pressure: ≤ 400 bar
Working temperature: - 20 ℃～+120 ℃
Reciprocating speed: ≤ 1.5m/s
Medium: General mineral-based hydraulic oil, water glycol hydraulic oil, oil-water emulsified hydraulic oil.
Installation: This type of seal can be used with an integral piston. To avoid damage to the sealing lip, measures should be taken to avoid sharp edges during installation.
Hydraulic piston seal SPGW-280 280x252x17 NBR80/PTFE+Bronze/polyamide resin up to 400 bar KVK/China, KOMATSU 707-44-28080,707-44-28180
Product data
ØD=280 mm; Ød=252 mm; H=17 mm; L=17.5 mm
Material: NBR80/PTFE+Bronze/polyamide resin
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 400 bar
Speed: ≤ 1.5 m/s
Temperature: -20°C ~ +120°C
Media: mineral-based hydraulic oils
OE references:
707-44-28080,707-44-28180
Suitable for Komatsu:
Buldozers/ Булдозери: D155S, D475A
Cranes/Кранове: LW160, LW200L, LW250L
Exavators /Багери: PC1600, PC1600SP
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 10 pcs.
Hydraulic piston seal SPGW-260 260x232x17 NBR80/PTFE+Bronze/polyamide resin up to 400 bar KVK/China,KOMATSU 707-44-26180
Product data
ØD=260 mm; Ød=232 mm; H=17 mm; L=17.5 mm
Material: NBR80/PTFE+Bronze/polyamide resin
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 400 bar
Speed: ≤ 1.5 m/s
Temperature: -20°C ~ +120°C
Media: mineral-based hydraulic oils
OE references:
707-44-26180
Suitable for Komatsu:
Wheel Loaders/ Колесни товарачи:
WA800-1,WA800-1-13,WA800-1-A,WA800-2,WA800-2L,WA800-2LC,WA800-3,WA800-3E0,WA800-3LC,WA800L-3,WA900-1,WA900-1L,WA900-1LC A20008-UP,WA900-3,WA900-3E0,WA900-3LC,WA900L-3
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 10 pcs.
Hydraulic piston seal SPGW-250 250x222x17 NBR80/PTFE+Bronze/polyamide resin up to 400 bar KVK/China ,KOMATSU 707-44-25080, 707-44-25180, 707-44-25190
Product data
ØD=250 mm; Ød=222 mm; H=17 mm; L=17.5 mm
Material: NBR80/PTFE+Bronze/polyamide resin
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 400 bar
Speed: ≤ 1.5 m/s
Temperature: -20°C ~ +120°C
Media: mineral-based hydraulic oils
OE references:
707-44-25080, 707-44-25180, 707-44-25190
Suitable for Komatsu:
Buldozers/ Булдозери:
D375A-3,D375A-3-01,D375A-3A,D375A-3A-01,D375A-5,D375A-5E0,D475A-2,D475A-3,D475A-3-HD,D475A-3-SC,D475A-5,D475A-5A,D475A-5E0,D475ASD-5E0
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 10 pcs.
Hydraulic piston seal SPGW-225 225x202x15.5 NBR80/PTFE+Bronze/polyamide resin up to 400 bar KVK/China, KOMATSU 707-44-22290,707-44-22280,707-44-22180,707-44-22080
Product data
ØD=225 mm; Ød=202 mm; H=15.5 mm; L=16mm
Material: NBR80/PTFE+Bronze/polyamide resin
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 400 bar
Speed: ≤ 1.5 m/s
Temperature: -20°C ~ +120°C
Media: mineral-based hydraulic oils
OE references:
707-44-22290,707-44-22280,707-44-22180,707-44-22080
Suitable for Komatsu:
Buldozers/ Булдозери:
D155A-2,D155A-2A,D155W-1,D275A-2,D355A-3,D355A-3X,D355A-5,D375A-2,D375A-3,D375A-3-01,D375A-3A,D375A-3A-01,D375A-3D,D375A-5D,D575A-2
Compactors/Уплътняващи машини:
WF550-3D
Wheel Loaders/ Колесни товарачи:
WA1200-3,WA400-1,WA420-3MC,WA450-5L,WA470-5,WA480-5,WA480-5L,WA500-1,WA500-1L,WA500-1LC,WA500-1LE,WA500-3,WA500-3H,WA500-3L,WA500-3LK,WA700-1,WA700-1L,WA700-3,WA700-3L
Exavators /Багери:
PC1000-1,PC1000LC-1,PC1000SE-1,PC1000SP-1,PC1100-6,PC1100LC-6,PC1100SE-6,PC1100SP-6,PC1250-7,PC1250-8,PC1250-8R,PC1250LC-7,PC1250LC-8,PC1250SE-7,PC1250SP-7,PC1250SP-8,PC1250SP-8R,PC1600-1,PC650-3,PC650-5,PC650LC-3,PC650LC-5,PC650SE-3,PC650SE-5,PC750-6,PC750-6-AM,PC750-7,PC750LC-6K-01,PC750SE-6,PC750SE-6-AM,PC750SE-6K,PC750SE-6K-01,PC750SE-6K-J,PC750SE-6K-LS,PC750SE-7,PC750SE-7-M1,PC750SE-7K,PC800-8PC800-8R,PC800SE-6,PC800SE-6-AM,PC800SE-7,PC800SE-7-M1,PC800-8E0,PC800-8R1
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 10 pcs.
Hydraulic piston seal SPGW-200 200x177x15.5 NBR80/PTFE+Bronze/polyamide resin up to 400 bar KVK/China, KOMATSU 424-63-H0P10,707-44-20080,707-44-20180,707-44-20190
Product data
ØD=200 mm; Ød=177 mm; H=15.5 mm; L=16mm
Material: NBR80/PTFE+Bronze/polyamide resin
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 400 bar
Speed: ≤ 1.5 m/s
Temperature: -20°C ~ +120°C
Media: mineral-based hydraulic oils
OE references:
424-63-H0P10,707-44-20080,707-44-20180,707-44-20190
Подходящ за Komatsu:
Buldozers/ Булдозери:
D155A-3,D155A-5,D155AX-3,D155AX-5,D275A-2,D375A-2,D375A-3,D375A-3-01,D375A-3A,D375A-3A-01,D375A-3D,D375A-5D,D375A-6,D475A-3
Compactors/Уплътняващи машини:
WF450-3WF550-3D
Wheel Loaders/ Колесни товарачи:
WA320PT-5L,WA350-1,WA350-3A-S,WA380-5,WA380-5-SN,WA380-5L,WA400-1,WA400-3-H,WA400-3-X,WA400-3A,WA400-3A-S,WA400-3A-SN,WA400-5L,WA420-1,WA420-3,WA420-3CS,WA420-3L,WA420-3MC,WA420-DZ-3 Serial No.10001 and up,WA430-5,WA450-1,WA450-2,WA450-3,WA450-3-H,WA450-3-X,WA450-3A,WA450-3A-S,WA450-3MC,WA450-5L,WA450L-3,WA470-1,WA470-3,WA470-5,WA470-DZ-3 Serial No.20118 and up,WA500-1,WA500-1L,WA500-1LC,WA500-1LE,WA500-3,WA500-3H,WA500-3L,WA500-3LK
Exavators /Багери:
PC1000-1,PC1000LC-1,PC1100-6,PC1100LC-6,PC1100SE-6,PC1100SP-6,PC1250-7,PC1250-8,PC1250-8R,PC1250LC-7,PC1250LC-8,PC1600-1,PC1600-1-A,PC1600SP-1,PC1800-6,PC1800-6-M1,PC300LL-7E0,PC340-6K,PC340LC-6K,PC340NLC-6K,PC350LC-8,PC350LL-7E0,PC350NLC-8,PC380LC-6K,PC600-6,PC600-6A,PC600-6A-KJ,PC600-6KPC600-6KJ,PC600-7,PC600-7-M1,PC600-7K,PC600-8,PC600-8R,PC600LC-6,PC600LC-6A,PC600LC-6A-KJ,PC600LC-6K,PC600LC-6KJ,PC600LC-7,PC600LC-7-M1,PC600LC-7K,PC600LC-8,PC600LC-8R,PC650-3 & ,PC650LC-3,PC650-3PC650-5 & PC650LC-5,PC650-5,PC650-6,PC650-6A,PC650-7-M1,PC650LC-3,PC650LC-5,PC650LC-6,PC650LC-6A,PC650LC-7-M1,PC650SE-3,PC650SE-5,PC710-5,PC710SE-5,PC750-6,PC750-6-AM,PC750-7,PC750-7-M1,PC750LC-6,PC750LC-6K-01,PC750LC-7,PC750LC-7K,PC750SE-6,PC750SE-6-AM,PC750SE-6K,PC750SE-6K-01,PC750SE-6K-JP,C750SE-6K-LS,PC750SE-7,PC750SE-7-M1,PC750SE-7K,PC800-6,PC800-6-AM,PC800-7,PC800-7-M1,PC800-8,PC800-8R,PC800SE-6,PC800SE-6-AM,PC800SE-7,PC800SE-7-M1,PC600-8E0,PC600-8R1,PC600LC-8E0,PC600LC-8R1,PC800-8E0,PC800-8R1
Wheel Dozers/Колесни булдозери:
WD900-3
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 9 pcs.
Hydraulic piston seal SPGW-185 185x162x15.5 NBR80/PTFE+Bronze/polyamide resin up to 400 bar KVK/China, KOMATSU 707-44-18250,707-44-18280,707-44-18290
Product data
ØD=185 mm; Ød=162 mm; H=15.5 mm; L=16mm
Material: NBR80/PTFE+Bronze/polyamide resin
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 400 bar
Speed: ≤ 1.5 m/s
Temperature: -20°C ~ +120°C
Media: mineral-based hydraulic oils
OE references:
707-44-18250,707-44-18280,707-44-18290
Suitable for Komatsu:
Exavators /Багери:
PC240LC-8K,PC240NLC-8K,PC400LCSE-8R,PC450-8,PC460LC-8,PC490LC-10,PC600-8,PC600-8R,PC600LC-8,PC600LC-8R,PC650LC-8E0,PC700LC-8E0,PC800-8K,PC800LC-8,PC800LC-8K,PC800SE-8,PC800SE-8R,PC850-8,PC850-8R,PC850SE-8,PC850SE-8RPW200-7E0PW220-7E0,PC240LC-10,PC240NLC-10,PC290LC-10,PC290NLC-10,PC400-8PC400-8R,PC400LC-8,PC400LC-8R,PC450-8R,PC450LC-8,PC450LC-8R,PC490-10,PC490LC-11,PC550LC-8,PC600-8E0,PC600-8R1,PC600LC-8E0,PC600LC-8R1,PC700LC-8R,PC800-8E0,PC800-8R1,PC800LC-8E0,PC800LC-8R1,PC800SE-8E0,PC800SE-8R1,PC850-8E0,PC850-8R1,PC850SE-8E0,PC850SE-8R1
Wheel Dozers/Колесни булдозери:
WA500-7
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 10 pcs.
Hydraulic piston seal SPGW-180 180x157x15.5 NBR80/PTFE+Bronze/polyamide resin up to 400 bar KVK/China, KOMATSU 707-44-18080,707-44-18180,707-44-18190,423-63-H3P06
Product data
ØD=180 mm; Ød=157 mm; H=15.5 mm; L=16mm
Material: NBR80/PTFE+Bronze/polyamide resin
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 400 bar
Speed: ≤ 1.5 m/s
Temperature: -20°C ~ +120°C
Media: mineral-based hydraulic oils
OE references:
707-44-18080,707-44-18180,707-44-18190,423-63-H3P06
Suitable for Komatsu:
Buldozers/ Булдозери:
D135A-1,D135A-2,D155A-3,D155A-5,D155AX-3,D155AX-5,D275A-2,D275A-5,D275A-5D,D275A-5R,D275AX-5,D275AX-5-KO,D275AX-5E0,D375A-6,D475A-2,D475A-3,D475A-3-HD,D475A-3-SC
Compactors/Уплътняващи машини:
WF450-3
Cranes/Кранове:
LW250-5X
Crawler Loaders/ Верижни товарачи:
D66S-1,D75S-5
Crawler Stabilizers/ Верижни стабилизатори:
CS360SD-2
Wheel Loaders/ Колесни товарачи:
WA250PT-5,WA250PT-5L,WA250PTL-5,WA270-5,WA300-1,WA300-3A,WA300-3A-X,WA320-5,WA320-5L,WA320-6,WA350-1,WA350-3-H,WA350-3-X,WA350-3A,WA350-3A-S,WA380-1,WA380-1LC,WA380-3 active,WA380-3,WA380-3MC,WA380-5,WA380-5-SN,WA380-5-TN,WA380-5L,WA380-DZ-3 Serial No.10580 and up,WA400-5,WA400-5L,WA450-1WA450-2,WA450-3,WA450-3-H,WA450-3-X,WA450-3A,WA450-3A-S,WA450-3A-TN,WA450-3MC,WA450-5L,WA450L-3,WA470-1,WA470-3,WA470-5,WA470-DZ-3 Serial No.20118 and up,WA480-5,WA480-5L
Exavators /Багери:
PC1000-1,PC1000LC-1,PC1600-1,PC400-3,PC400LC-3,PC650-3 & PC650LC-3,PC650-3P,C650-5 & PC650LC-5,PC650-5,PC650LC-3,PC650LC-5,PC650SE-3,PC650SE-5,PC710-5
Wheel Dozers/Колесни булдозери:
WD600-1,WD600-1H,WD600-3,WD600-6
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 10 pcs.
Hydraulic piston seal SPGW-165 160x142x15.5 NBR80/PTFE+Bronze/polyamide resin up to 400 bar KVK/China, KOMATSU 707-44-16280
Product data
ØD=165 mm; Ød=142 mm; H=15.5 mm; L=16mm
Material: NBR80/PTFE+Bronze/polyamide resin
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 400 bar
Speed: ≤ 1.5 m/s
Temperature: -20°C ~ +120°C
Media: mineral-based hydraulic oils
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 10 pcs.
Hydraulic piston seal SPGW-160 160x137x15.5 NBR80/PTFE+Bronze/polyamide resin up to 400 bar KVK/China,KOMATSU 707-44-16080,707-44-16150,707-44-16180,707-44-16190,423-63-H2P06
Product data
ØD=160 mm; Ød=137 mm; H=15.5 mm; L=16mm
Material: NBR80/PTFE+Bronze/polyamide resin
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 400 bar
Speed: ≤ 1.5 m/s
Temperature: -20°C ~ +120°C
Media: mineral-based hydraulic oils
OE references:
707-44-16080,707-44-16150,707-44-16180,707-44-16190,707-44-16280,423-63-H2P06
Suitable for Komatsu:
Backhoeloaders/Багер-товарачи:
D135A-1,D135A-2,D155A-3,D155A-5,D155AX-3,D155AX-5,D275A-5,D275A-5D,D275A-5R,D275AX-5,D275AX-5-KO,D275AX-5E0,D355A-3,D355A-3X,D355A-5,D50P-18,D53P-18,D60A-11,D60A-11D,D60E-8,D60P-11,D60P-11D,D60P-8,D60PL-8,D65A-11,D65A-11D,D65E-8,D65P-11,D65P-11D,D65P-8,D75A-1,D85A-21,D85A-21-E,D85E-21
Compactors/Уплътняващи машини:
WF650T-3
Wheel Loaders/ Колесни товарачи:
WA200PT-5,WA200PT-5L,WA200PTL-5,WA300-1,WA300-3A,WA300-3A-SN,WA300-3A-X,WA300-3CS,WA300L-3,WA320 AVANCE CUSTOM Serial No.20001 and up,WA320-1,WA320-1LC,WA320-3,WA320-3CS,WA320-3L,WA320-3MC,WA320-5,WA320-5L,WA320-6 Highlift,WA320-6,WA320L-5,WA350-3-H,WA350-3-X,WA350-3A,WA350-3A-S,WA350-3A-SN,WA380-1,WA380-3,WA380-3MC,WA380-5,WA380-5-SN,WA380-5-TN,WA380-5L,WA380-DZ-3 Serial No.10580 and up,WA400-1,WA400-3-H,WA400-3-X,WA400-3A,WA400-3A-S,WA400-3A-SN,WA400-5,WA400-5L,WA420-1LC,WA420-3,WA420-3CS,WA420-3L,WA420-3MC,WA420-DZ-3 Serial No.10001 and up,WA430-5,WA800-1,WA800-1-13,WA800-1-A,WA800-2,WA800-2L,WA800-2LC,WA800-3,WA800-3E0,WA800-3LC,WA800L-3,WA900-1L,WA900-1LC A20008-UP,WA900-3,WA900-3E0,WA900-3LC,WA900L-3
Exavators /Багери:
PC1100-6PC1100LC-6PC1100SE-6PC1100SP-6PC1250-7PC1250-8PC1250-8RPC1250LC-7PC1250SE-7PC1250SP-7PC150-6KPC150LC-6KPC160-6KPC160LC-7KPC180LC-6KPC180NLC-6KPC200-6PC200-6 Serial NO.60001 and up, PC200LC-6 Serial NO.70001 and upPC200-6HPC200-6JPC200-6SPC200-6S,PC200LC-6S PC200-6ZPC200EL-6KPC200EN-6KPC200LC-6PC200LC-6HPC200LC-6JPC200LC-6SPC200LC-6ZPC210-6KPC210LC-6KPC228US-3-YAPC270-7-AGPC290LC/NLC-8 HIGH REACH DEMOLITIONPC300PC300-5PC300-5CPC300-5KPC300-6PC300-6 SERIAL NUMBERS:J10295PC300-6ZPC300-7PC300-7 SERIAL NUMBERS : J20001-UPPC300-7-AAPC300-7E0PC300-8PC300HD-5KPC300HD-7E0PC300HD-7LPC300HD-8 s/n A87001 and upPC300LCPC300LC-5PC300LC-5KPC300LC-5LCPC300LC-6PC300LC-6LC/HD-6LC/HD-6MHPC300LC-6LE/HD-6LEPC300LC-6ZPC300LC-7PC300LC-7-BAPC300LC-7E0PC300LC-7LPC300LC-8PC300LL-7E0PC300LL-7LPC300NLC-5KPC300SC-6PC310-5PC310LC-5PC340-6KPC340LC-6KPC340LC-6K-JPC340LC-7KPC340LC-7K-E0PC340NLC-6PC340NLC-6KPC340NLC-7KPC340NLC-7K-E0PC350-6PC350-6ZPC350-7PC350-7-AAPC350-7E0PC350-8PC350HD-8PC350LC-6PC350LC-6ZPC350LC-7PC350LC-7-BAPC350LC-7E0PC350LC-8PC350LC/NLC-8K HIGH REACH DEMOLITION (23 M)PC350LL-7E0PC350NLC-8PC360-7PC380LC-6KPC380LC-6K-JPC380LC-7KPC390LL-10 A50601 & UPPC400PC400-5PC400-5CPC400-5DPC400-6PC400-6CPC400-6ZPC400-7PC400-7 SERIAL NUMBERS : J20001-UPPC400-7-M1PC400-7E0PC400-8PC400HD-5KPC400LCPC400LC-5PC400LC-6PC400LC-6LC/HD-6LCPC400LC-6LK/HD-6LKPC400LC-6LM/HD-6LMPC400LC-6ZPC400LC-7PC400LC-7-M1PC400LC-7E0PC400LC-7LPC400LC-8PC400ST-6PC400ST-6LCPC410-5PC410LC-5PC450-6PC450-6KPC450-6K-JPC450-6K-KEPC450-6ZPC450-7PC450-7-M1PC450-7E0PC450-7KPC450-7K-E0PC450-8PC450LC-6PC450LC-6KPC450LC-6K-JPC450LC-6K-KEPC450LC-6ZPC450LC-7PC450LC-7-M1PC450LC-7E0PC450LC-7KPC450LC-7K-E0PC450LC-8PC450LCHD-8PC600-6APC600-7PC600-8PC600-8RPC600LC-6APC600LC-8PC600LC-8RPW128UU-1PW150ES-6KPW160-7PW160-7E0PW160-7KPW170ES-6KPW170ES-6K-KAPW180-7E0PW180-7KPC400-8RPC400LC-8RPC450-8RPC450LC-8RPC550LC-8PC600-8E0PC600-8R1PC600LC-8E0PC600LC-8R1PW180-10
Wheel Dozers/Колесни булдозери:
WD600-1WD600-1HWD600-3WD600-6WD900-3
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 10 pcs.
Hydraulic piston seal SPGW-150 150x127x15.5 NBR80/PTFE+Bronze/polyamide resin up to 400 bar KVK/China, KOMATSU 707-44-15080,707-44-15150,707-44-15180,707-44-15190
Product data
ØD=150 mm; Ød=127 mm; H=15.5 mm; L=16mm
Material: NBR80/PTFE+Bronze/polyamide resin
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 400 bar
Speed: ≤ 1.5 m/s
Temperature: -20°C ~ +120°C
Media: mineral-based hydraulic oils
OE references:
707-44-15080,707-44-15150,707-44-15180,707-44-15190
Suitable for Komatsu:
Buldozers/ Булдозери:
D135A-1D135A-2D375A-2D375A-3D375A-3-01D375A-3AD375A-3A-01D375A-3DD375A-5DD50A-18D53A-18D53P-18AD58E-1BD58P-1BD58P-1CD85EX-15D85EX-15E0D85EX-15RD85MS-15D85PX-15D85PX-15E0D85PX-15R
Backhoeloaders/Багер-товарачи:
D57S-1BD66S-1D85MS-15
Drum Trucks/Самосвали:
HD465-5HD465-7HD465-7E0HD465-7RHD605-5HD605-7HD605-7E0HD605-7R
Exavators /Багери:
PC270-7PC270-7-AGPC270LC-6LEPC270LC-7LPC270LL-7LPC290LC-6KPC290LC-7KPC290NLC-6KPC290NLC-7KPC300-7PC300-7 SERIAL NUMBERS : J20001-UPPC300-7E0PC300-8PC300HD-7LPC300HD-8 s/n A87001 and upPC300LC-7PC300LC-7E0PC300LC-7LPC300LC-8PC308USLC-3PC340LC-7KPC340LC-7K-E0PC340NLC-7KPC340NLC-7K-E0PC350-7E0PC350-8PC350HD-8PC350LC-7PC350LC-7E0PC350LC-8PC350NLC-8PC360-7PC380LC-7KPC70-7PC70-7-BPC70-7EPC70-7E-B
Wheel Loaders/ Колесни товарачи:
WA200-1WA200-3WA200-3-XWA200PZ-6WA250-1LCWA250-3WA250-3-SNWA250-3LWA250-3MCWA250-5WA250-5LWA250-6 HighliftWA250-6WA250L-3WA250L-5WA270-5WA270-5-SNWA350-1WA430-6
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 10 pcs.
