Hydraulic rod seal TSE AI 80x95x12 NBR+fab.NBR+POM up to 400 bar GUARNITEC/Italy
Product data
d=80 mm; D=95 mm; H=12 mm
Material: NBR+fab.NBR+POM
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 400 bar
Speed: ≤ 0.5 m/s
Temperature: -35°C to +110°C ; -20°C +200°C FKM
Media: mineral-based hydraulic oils
Manufacturer:
GUARNITEC S.r.l.
100% Made in Italy
For delivery options to your country, please do not hesitate to contact us!
Product photos are for illustrative purposes and may differ from the actual appearance of the item. This does not affect the characteristics of the product.
In stock 17 pcs.
Hydraulic piston and rod seal USH 14x22x6 NBR90 up to 210 bar KVK/China
Product data
The hydraulic seal USH has a symmetrical design and is suitable for both piston and rod.
Ød=14 mm; ØD=22 mm; h=6 mm
Material: NBR90
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 210 bar; when the pressure is higher than 150 bar, it is recommended to use a back-up ring
Speed: ≤ 0.5 m/s
Temperature: -30°C ~ +100°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 94 pcs.
Hydraulic piston and rod seal UN 12x20x5 PU93 up to 320 bar KVK/China
Product data
Ød=12 mm; ØD=20 mm; h=5 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 55 pcs.
Hydraulic piston and rod seal Y 10x22x6 NBR80 up to 200 bar KVK/China
Product data
The hydraulic seal Y has a symmetrical design and is suitable for both piston and rod.
Ød=10 mm; ØD=22 mm; H=6 mm; Ød1=10.6 mm; ØD1=21.4 mm; L=6 mm
Material: NBR80
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 200 bar
Speed: ≤ 0.5 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 20 pcs.
Hydraulic piston and rod seal UPH-10C 10x20x6 NBR90 up to 320 bar KVK/China
Product data
The hydraulic seal UPH has a symmetrical design and is suitable for both piston and rod.
Ød=10 mm; ØD=20 mm; h=6 mm; ØD1=19 mm; HA=7 mm; HB=10 mm; r=2.5 mm
Material: NBR90
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 150 bar, it is recommended to use a back-up ring
Speed: ≤ 0.5 m/s
Temperature: -30°C ~ +100°C
Media: mineral hydraulic oils, water-glycol hydraulic oils, emulsions
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 20 pcs.
Hydraulic piston and rod seal UPH-10B 10x16x4 NBR90 up to 320 bar KVK/China
Product data
The hydraulic seal UPH has a symmetrical design and is suitable for both piston and rod.
Ød=10 mm; ØD=16 mm; h=4 mm; ØD1=15 mm; HA=4.7 mm; HB=6.2 mm; r=2.5 mm
Material: NBR90
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 150 bar, it is recommended to use a back-up ring
Speed: ≤ 0.5 m/s
Temperature: -30°C ~ +100°C
Media: mineral hydraulic oils, water-glycol hydraulic oils, emulsions
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 95 pcs.
Hydraulic piston/ rod seal UN 10x14x2.5 PU92 SOG/TW
Hydraulic piston/rod seal with symmetrical design.
ID: 10.0 mm
OD: 14.0 mm
Width: 2.5 mm
Material: PU92
Adaptable temperature: -20 ~ 100 C
Maximum working pressure: 350 bar (35Mpa)
Manufacturer: SO GIANT OIL SEAL INDUSTRIAL CO., LTD
For delivery options to your country, please do not hesitate to contact us!
In stock 40 pcs.
Hydraulic piston/ rod seal UN 8x14x4 PU92 SOG/TW
Hydraulic piston/rod seal with symmetrical design.
ID: 8.0 mm
OD: 14.0 mm
Width: 4.0 mm
Material: PU92
Adaptable temperature: -20 ~ 100 C
Maximum working pressure: 350 bar (35Mpa)
Manufacturer: SO GIANT OIL SEAL INDUSTRIAL CO., LTD
For delivery options to your country, please do not hesitate to contact us!
In stock 100 pcs.
Guide ring WR 55x60x8 fabric reinforced phenolic resin KVK/China
Product data
Ød=55 mm; ØD=60 mm; h=8 mm
Material: Fabric-reinforced phenolic resin
Application range (the following limit values cannot appear at the same time):
Speed: ≤ 0.5 m/s
Temperature: -50°C ~ +120°C
Media: mineral-based hydraulic oils and emulsions
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 20 pcs.
Guide ring WR 312x320x25 fabric reinforced phenolic resin KVK/China
Product data
Ød=312 mm; ØD=320 mm; h=25 mm
Material: Fabric-reinforced phenolic resin
Application range (the following limit values cannot appear at the same time):
Speed: ≤ 0.5 m/s
Temperature: -50°C ~ +120°C
Media: mineral-based hydraulic oils and emulsions
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 2 pcs.
