- Advanced Material Engineering: Backed by dedicated research units, KVK continuous to innovate in high-grade elastomer synthesis, ensuring maximum hydraulic fluid resistance and high tensile strength under load.
- Colossal Warehousing Capabilities: Operating as a main production and logistics hub, the factory holds vast baseline stock volumes, empowering "Satelit Nikis" to secure even the most specialized and rare sealing dimensions rapidly.
- Strict Quality Metrics: All manufacturing operations strictly mirror the global quality framework of ISO 9001, guaranteeing crisp sealing lip geometries and zero defects.
954
products
Products
Hydraulic piston and rod seal UPH-45F 45x63x10 NBR90 up to 320 bar KVK/China
Product data
The hydraulic seal UPH has a symmetrical design and is suitable for both piston and rod.
Ød=45 mm; ØD=63 mm; h=10 mm; ØD1=62 mm; HA=11 mm; HB=14 mm; r=4 mm
Material: NBR90
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 150 bar, it is recommended to use a back-up ring
Speed: ≤ 0.5 m/s
Temperature: -30°C ~ +100°C
Media: mineral hydraulic oils, water-glycol hydraulic oils, emulsions
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 16 pcs.
Hydraulic piston and rod seal UN 45x55x7 PU93 up to 320 bar KVK/China
Product data
Ød=45 mm; ØD=55 mm; h=7 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 88 pcs.
Hydraulic piston and rod seal UN 40x60x10 PU93 up to 320 bar KVK/China
Product data
Ød=40 mm; ØD=60 mm; h=10 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 32 pcs.
Hydraulic piston and rod seal UN 40x50x5 PU93 up to 320 bar KVK/China
Product data
Ød=40 mm; ØD=50 mm; h=5 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 28 pcs.
Hydraulic piston and rod seal UN 40x48x6 PU93 up to 320 bar KVK/China
Product data
Ød=40 mm; ØD=48 mm; h=6 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 86 pcs.
Hydraulic piston and rod seal UN 35x43x6 PU93 up to 320 bar KVK/China
Product data
Ød=35 mm; ØD=43 mm; h=6 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 87 pcs.
Hydraulic piston and rod seal UN 25x35x7 PU93 up to 320 bar KVK/China
Product data
Ød=25 mm; ØD=35 mm; h=7 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
Hydraulic piston and rod seal UN 24x34x6 PU93 up to 320 bar KVK/China
Product data
Ød=24 mm; ØD=34 mm; h=6 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 13 pcs.
Hydraulic piston and rod seal UN 20x28x6 PU93 up to 320 bar KVK/China
Product data
Ød=20 mm; ØD=28 mm; h=6 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 45 pcs.
Hydraulic piston and rod seal UN 20x28x5.5 PU93 up to 320 bar KVK/China
Product data
Ød=20 mm; ØD=28 mm; h=5.5 mm
Material: PU93
Application range (the following limit values cannot appear at the same time):
Pressure: ≤ 320 bar; when the pressure is higher than 200 bar, it is recommended to use a back-up ring
Speed: ≤ 0.8 m/s
Temperature: -30°C ~ +80°C
Media: mineral-based hydraulic oils and emulsions; not suitable for environmetally-friendly oils (bio oils)
Manufacturer:
Zhongxingshun Sealing Products Factory
In stock 62 pcs.
